 Page 1 / 5

AR - 102   1/4" Air Ratchet









Speed ( RPM )

240

Bolt Capacity

5/16"

Square Driver

1/4"

Max Torque ( FT/LBS )

18

Air Pressure ( PSI )

90

Avg. Air Consumption ( CFM )

4

Air Inlet ( NPT )

1/4"

Hose Size ( ID )

5/16"

Overall Length

8"

Weight ( KG )

0.64



AR-103     3/8" Air Ratchet




@







Speed ( RPM )

160

Bolt Capacity

3/8"

Square Driver

3/8"

Max Torque ( FT/LBS )

50

Air Pressure ( PSI )

90

Avg. Air Consumption ( CFM )

4

Air Inlet ( NPT )

1/4"

Hose Size ( ID )

3/8"

Overall Length

10"

Weight ( KG )

1.15



AR-104     1/2" Air Ratchet

@

@

 @


@



Speed ( RPM )

160

Bolt Capacity

3/8"

Square Driver

1/2"

Max Torque ( FT/LBS )

50

Air Pressure ( PSI )

90

Avg. Air Consumption ( CFM )

4

Air Inlet ( NPT )

1/4"

Hose Size ( ID )

3/8"

Overall Length

10"

Weight ( KG )

1.15



AR-103H    3/8" Air Ratchet







Speed ( RPM )

160

Bolt Capacity

1/2"

Square Driver

3/8''

Max Torque ( FT/LBS )

60

Air Pressure ( PSI )

90

Avg. Air Consumption ( CFM )

4

Air Inlet ( NPT )

1/4"

Hose Size ( ID )

3/8"

Overall Length

10-3/8"

Weight ( KG )

1.15
